Delta HexaVolt
Multi-Unit Buildings Distribution Transformers
Delta HexaVolt is designed to simplify and improve electrical systems in multi-unit apartment buildings. By combining three single-phase transformers into one efficient unit, this innovative solution cuts down on installation time, saves space, and enhances energy efficiency.
Key Benefits
38%
LESS SURFACE AREA*
The compact design minimizes space and reduces heat rejection, making it easier to fit within electrical room constraints.
20%
ENERGY SAVINGS*
Operating on a three-phase system, this transformer is more efficient than 3 single-phase systems used at full load, leading to lower energy consumption and cost savings over time.
66%
LESS INSTALLATION TIME*
With just one transformer to install, the process requires less time and fewer materials, reducing overall installation costs.
*When compared to three single-phase transformers.
Traditional Setup vs. Delta HexaVolt Solution
Single-phase transformers are commonly used to power multi-unit residential
buildings. Typically, this set-up involves three transformers, multiple anchors,
three switches, and numerous bulky cables, cluttering often cramped electrical rooms.
The HexaVolt transformer simplifies this set-up with a compact, all-in-one
solution that includes one three-phase transformer, three single-phase outputs
and requires only four anchors, and one switch.
- kVA: 150, 225, 300, 450, 600
- Frequency: 60 Hz
- Phase: Delta connected primary. Secondary winding shall be wye connected with neutral conductor center-tapped on each phase providing 120V line-neutral and 240V and 208V phase to phase. Two full capacity 2.5% adjustment taps, 2 below (FCBN) and 2 above (FCAN)
- Winding Material: Aluminium
- Insulation System: 220°C Insulation Class. 150°C Temperature rise
- BIL Rating: 10 kV BIL
- Enclosure Type: Ventilated, Type 3R sprinkler-proof enclosure
- Impregnation Process: The impregnation process for the core-and-coil assembly shall include a period under vacuum, followed by pressure impregnation using epoxy resin (EVI process)
- Enclosure Finish: Grey finish ANSI-61
- Neutral: 3 or 6 lugs (varies by kVA)
- Conduit Entry: 2 knock-outs on each side
- Impedance: Standard Impedance
- Mounting: Floor mount only
- Efficiency: Complies with Canadian standards - SOR/2018-201 (NRCan 2019), Ontario Regulation 404/12 and Quebec: O.C./DECRET/1394-2018
- Sound Level: Max. 50dB up to 150 kVA, 55 dB from 225 kVA to 300 kVA and 60 dB at 450 kVA and 62dB at 600 kVA. Anti-vibration pads used between the core and the enclosure
- Certification: CSA certified
- Warranty: 10 year warranty with standard limited liability clause
